The Yamaha MGX12 Digital Mixing Console combines professional sound quality, intuitive touchscreen control, and flexible connectivity in a compact, portable format. Designed for live sound, streaming, podcasting, recording, and installed audio systems, the MGX12 delivers advanced digital mixing features while remaining fast and easy to operate.
The Yamaha MGX12 Digital Mixing Console builds on the legendary reputation of Yamaha’s MG Series, combining professional sound quality, flexible connectivity, and intuitive operation in a compact digital mixer designed for modern audio applications.
Ideal for live sound, installed audio systems, podcasting, live streaming, music production, and recording, the MGX12 delivers powerful functionality with an easy-to-use workflow.
Compact Digital Mixer with Professional Features
- 11 + 1 non-motorized fader configuration
- 4.3-inch touchscreen display with physical controls
- Lightweight design at only 3.9 kg
- Rugged construction for portable and installed use
Flexible Input & Output Configuration
Inputs
- 4 Mic/Line combo inputs
- 4 stereo line inputs
- Bluetooth audio input
- Sound Pad and FX return channels
Outputs
- 2 XLR outputs
- 6 TRS outputs
- 4 headphone outputs
Designed for bands, venues, podcasts, streaming setups, and recording applications.
Premium Yamaha Sound Quality
- High-performance MGX microphone preamps
- 86 dB gain range with ultra-low distortion
- 125 dB dynamic range at stereo output
- Professional-grade AD/DA conversion
Built around Yamaha’s renowned “True Sound” philosophy.
Powerful DSP & Effects
- Built-in DSP processor with low-latency monitoring
- Includes:
- EQ
- Compressor
- Gate
- Reverb
- Amp Simulator
- Voice Changer
- Multi-band Compressor
- Delay
Intelligent Workflow Features
- Auto Gain for fast level setup
- Clip Safe protection against distortion
- Scene Recall for instant setup changes
- Simple & Standard operating modes
Recording & Streaming Ready
USB Audio Interface
- 18-in / 18-out USB MAIN (32-bit / 96kHz)
- 2-in / 2-out USB SUB
microSD Recording
- 16-track recording directly to microSD card
- 2-track playback support
Ideal for:
- Podcasting
- Streaming
- Mobile recording
- Live multitrack capture
Bluetooth & Sound Pads
- Bluetooth 5.0 audio streaming
- 8 customizable sound pads
- Trigger jingles, sound effects, or shortcuts instantly
Touchscreen & Real-Time Control
- Fast, intuitive touch-panel GUI
- 12 faders with dedicated send controls
- Four assignable knobs and TOUCH AND TURN control
Included Software & Accessories
Includes:
- Cubase AI
- WaveLab Cast
- Steinberg Plus
- Basic FX Suite
- AC Power Adapter
- Quick Start & Safety Guides
Key Features
- Compact digital mixing console
- Touchscreen operation with physical controls
- Professional DSP processing
- USB audio interface
- Bluetooth audio input
- Multitrack microSD recording
- Scene recall and assistive mixing tools
